what is 304 welded steel pipe

The quick, easy and free way to learn stainless steel welded tube & pipe

304 welded stainless steel pipe and tube

How to make the 304 stainless steel welded pipe

The stainless steel welded tube is produced through roll forming strips or sheets of stainless steel into a tube shape and then welding the seam lengthways.

Welded tubing can be formed by hot forming and cold forming processes. The cold-forming tubing is more smooth on finishes and more tight on tolerances. Both methods can make a strong and long-lasting steel tube that keeps from corrosion. The welded tube can be drawn similar to seamless tubing to produce a finer weld seam with better surface finishes and tighter tolerances, but the general compressive strength is lower than stainless steel seamless steel pipe.

304 stainless steel welded pipe weights calculation formula

304 stainless steel weldied pipe's theory weight calculation formula per meter weight:

M/kg=(outer diameter-wall thickness)xwall thickness x0.02491

Unit: outer diameter mm, wall thickness mm, weight kg

304 stainless steel welded pipe Standards

In different countries, the standards are different. Basically, the standards are drafted according to big steel plants' standards, the name is different, but the differences are not too huge.

304 Stainless steel welded pipe/tube sizes

OD Wall thickness
Standard thickness 0.6 0.7 0.8 0.9 1 1.2 1.5 2 2.5 3 4
Actual thickness 0.35 0.45 0.6 0.65 0.75 0.95 1.15 1.55 2.05 2.55 3.5
12.7 * * * * * * *
15.9 * * * * * * * *
19.1 * * * * * * * *
22.2 * * * * * * * * *
25.4 * * * * * * * * * *
31.8   * * * * * * * * *
38.1     * * * * * * * *
50.8     * * * * * * * *
63.5     * * * * * * * * *
76.2       * * * * * * * *
88.9         * * * * * * *
101.6         * * * * * * *
108           * * * * * *
114.3           * * * * * *
133             * * * * *
159             * * * * *

304 stainless steel welded pipe supplier

AHL STEEL, as a growing stainless steel supplier, the company has the following advantages:

  1. Professional packing team guarantee goods arriving in good condition;
  2. Professional loading team avoid package damage;
  3. Goods label with traceable batch number and shipping information;
  4. Strict quality control system make sure high quality;
  5. Varous sizes and materials stock more than 500 tons

304 stainless steel welded pipe supplier

Prices are changing in real time, so they are for reference only. To get the latest 304 stainless steel welded pipe price, welcome to contact us or just send email to info@offersteels.com

Grade MNQ(Ton) Price range(USD/TON)
201 1 1800~2100
304 1 2500~2900
