310/310S stainless steel pipe

What is 310 Stainless steel Pipe?

Grade 310 is an austenitic stainless steel, which offers exceptional high temperature properties, along with good ductility and weld ability. Type 310 stainless steel tubes are typically used for elevated temperature applications. High chromium and nickel content of 310 grade steel pipes provides excellent high temperature oxidation resistance and are good for continuous exposure to 2100 degree F Intermittent service to 1900 degree F. The higher chromium and nickel content, also makes it superior to 304 or 309 stainless hollow sections.
Grade 310S is a low carbon alternative of grade 310. It is used in a lower temperature range when the application environment involves moist corrodents. However, the lower carbon content reduces the high temperature strength of stainless steel grade 310S compared to 310.

AHL STEEL specialize in manufacturing, exporting and supplying outstanding quality Stainless Steel 310 Pipes. AHL supply high-quality SS pipes in Seamless, ERW, EFW, Welded & Fabricated with round, square, hex, oval, hollow, U and other shapes. 310 Stainless Steel Pipes are widely used in various industries such as cement & construction industries, pumps, sugar mills, and others.


SS 310 Pipes Fabrication:

• Mostly used in heat treatment and process industries in high temperature and corrosive environments
• Can be easily roller-formed, stamped, and drawn
• Usually fabricated into complex structures
• Grade ss 310 pipes harden after severe forming operations. Hence, it should be followed by annealing

Applications of Alloyed 310 Pipes:

Higher alloyed 310 pipes have excellent strength at elevated temperatures. Along with this, these stainless steel grade pipes offer outstanding resistance to creep deformation and environmental contaminants. Some usage examples of 310 steel include:

• Oil Burner Parts
• Heat Exchangers
• Furnace Parts
• Welding Filler Wires and Electrodes
• Combustion Tubes
• Annealing Covers
• Fire Box Sheets

Chemical Composition and Mechanical Properties：

Typical Chemical Composition %
Grade	C	Mn	P	Si	S	Ni	Cr	Mo	Fe
310	0.04 MIN	2.0 MAX	0.04 MAX	0.75 MAX	0.03 MAX	19.0 MIN	24.0 MIN	0.75 MAX	BLAANCE
310S	0.08 MAX	2.0 MAX	0.04 MAX	0.75 MAX	0.03 MAX	22.0 MAX	26.0 MAX	0.75 MAX	BALANCE

Typical Mechanical Properties
Grade	Tensile Strength KSI (min.)	Yield Strength 0.2% Offset KSI (min.)	Elongation (% in 2ʺ(50.8 mm)	Hardness (Brinell) MAX	Hardness (Rockwell B) MAX
310	75	30	40	217	95
310S	75	30	40	217	95
